FMUSER DTV-4619B 8/16/24 FTA DVB- S/S2/S2X (DVB-C/T/T2/ISDB-T/ATSC) or 2/1 ASI and 1 USB in 8/16/24 MPTS+2MPTS or 256/512/1024 SPTS through 2 IP out T
1.Support 8/16/24 FTA DVB- S/S2/S2X (DVB-C/T/T2 /ISDB-T/ATSC optional ) 2/1 ASI and 1 USB input, 2 ASI input
2.Support BISS descrambling, DisEqc function
3.8/16/24 MPTS+2MPTS or 256/512/1024 SPTS (MPTS and SPTS output switchable)
4.Support “Null PKT Filter” function (Only for MPTS output), PID filtering, re-mapping (Only for SPTS output)
5.Support QR code, LOGO, caption insertion
Details:
FMUSER DTV-4619B 8/16/24 FTA DVB- S/S2/S2X (DVB-C/T/T2/ISDB-T/ATSC) or 2/1 ASI and 1 USB in 8/16/24 MPTS+2MPTS or 256/512/1024 SPTS through 2 IP out Tuner to IPTV Gateway
Overview:
FMUSER DTV-4619B is a head-end interface conversion device which supports MPTS and SPTS output switchable. It supports 24 MPTS+2 MPTS(ASI and USB) or 1024 SPTS output over UDP and RTP/RTSP protocol. It is integrated with tuner demodulation (or ASI input) and gateway function; which can demodulate the signal from 24 tuners into IP package; or directly convert the TS from ASI input and tuner into IP package; then output the IP package through different IP address and ports. BISS function is also embedded for tuner input to descramble your tuner input programs. Also suitable Cable digital TV adjacent frequency front-end system; hotel IPTV network TV system and hotel satellite digital TV system.
Features:
BISS Function: The FMUSER DTV-4619B Tuner to IP Gateway also features BISS function for tuner input to descramble tuner input programs. This feature ensures that viewers receive high-quality content that is free from error and distortion.Input and Output Ports: FMUSER DTV-4619B Tuner to IP Gateway features 24 FTA DVB-S/S2/S2X input ports; 1 ASI input port; and 1 USB input port. It also offers 24 tuner input ports; Web port; GE1&2 IP output ports; and ASI input&output ports switchable. It also provides 2 independent GE output ports; GE1(512 SPTS)+ GE2(512 SPTS); resulting in a total output of 26 MPTS.Advanced Filtering and Re-mapping Features (Only for SPTS output): The DTV-4619B Tuner to IP Gateway supports advanced filtering and re-mapping features that allow users to customize their output signals. This feature-rich device supports PID filtering and re-mapping for SPTS output; ensuring that users receive high-quality signals that are free from errors.Null PKT Filter Function(Only for MPTS output): The DTV-4619B Tuner to IP Gateway also has a "Null PKT Filter" function for MPTS output. This feature ensures that the device only sends valid packets; eliminating the need to send unnecessary packets that could cause congestion on the network.Web-Based Management: FMUSER DTV-4619B Tuner to IP Gateway is easy to manage via web-based management. Users can easily configure and monitor the device remotely; reducing the need for physical interaction with the device.Conclusion: FMUSER DTV-4619B Tuner to IP Gateway is a feature-rich device that offers advanced signal processing; filtering; and re-mapping capabilities. It is a versatile solution that provides high-quality output signals; making it ideal for various broadcast applications.
Working Principle:
FMUSER DTV-4619B-8/16
FMUSER DTV-4619B-24
Specification:
| ||||||||||||||||||||||||||||||||||
|
|
Symbol rate | QPSK/8PSK / 16APSK :0.5~45 Msps | |||||||||||||||||||||||||||||||
FEC | QPSK: 1/2; 3/5; 2/3; 3/4; 4/5; 5/6; 8/9; 9/ 10; 13/45; 9/20; 11/20 | |||||||||||||||||||||||||||||||||
Constellation | QPSK; 8PSK; 8APSK; 16APSK; 32APSK | |||||||||||||||||||||||||||||||||
Max input bitrate | ≤125 Mbps | |||||||||||||||||||||||||||||||||
BISS Descrambling | Mode 1; Mode E (Up to 850Mbps) (descramble individual program) | |||||||||||||||||||||||||||||||||
Output | 1024 SPTS IP output over UDP and RTP/RTSP protocol through GE1 and GE2 port (IP address and port number of GE1 and GE2 are different) ; Unicast and Multicast | |||||||||||||||||||||||||||||||||
26 MPTS IP output (for Tuner/ASI/USB pass-through) over UDP and RTP/RTSP protocol through GE1 and GE2 port; Unicast and Multicast | ||||||||||||||||||||||||||||||||||
2 ASI output | ||||||||||||||||||||||||||||||||||
System | Web based management | |||||||||||||||||||||||||||||||||
Ethernet software upgrade | ||||||||||||||||||||||||||||||||||
Miscellaneous | Dimension | 482mm×230mm×44mm (W×L×H) | ||||||||||||||||||||||||||||||||
Approx weight | 2.5kg | |||||||||||||||||||||||||||||||||
Environment | 0~45C(work); -20~80C (Storage) | |||||||||||||||||||||||||||||||||
Power requirements | 100~240VAC; 50/60Hz | |||||||||||||||||||||||||||||||||
Power consumption | 20W | |||||||||||||||||||||||||||||||||
