FMUSER DTV-4335H/HV 4/8/12 HDMI/SDI HEVC/Mpeg4/H.264/H.265 in 4/8/12 SPTS OSD Encoder
1.4 or 8 or 12 HDMI or SDI inputs with SPTS and MPTS output
2.HEVC/H.265 & MPEG 4 AVC/H.264 video encoding format, IP output over UDP and RTP/RTSP protocol
3.MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2, AC3 Passthrough
4.OSD (Logo) insertion-Optional as per order
5.Control via web management, and easy updates via web
Details:
FMUSER DTV-4335H/HV 4/8/12 HD/SDI HEVC/Mpeg4/H.264/H.265 in 4/8/12SPTS OSD Encoder
Overview:
FMUSER DTV-4335H/HV 4/8/12 HD/SDI in encoder supports both HEVC/H.265 and MPEG 4 AVC/H.264 video encoding; allowing for high-quality video compression at low bitrates. The device also supports audio encoding with MPEG-1 Layer 2; LC-AAC; HE-AAC; HE-AAC V2; and AC3 Passthrough; providing users with a range of options to fine-tune their audio output. With the ultra-low bitrate feature; the device can save up to 75% bandwidth; making it ideal for use in digital distribution systems with limited bandwidth. The advanced compressing algorithm enhances picture quality; providing users with a more immersive viewing experience. The device also features advanced pretreatment functions such as de-interlacing; noise reduction; and sharpening to further improve video quality. Additionally; optional OSD (On-Screen Display) features; such as logo and QR code insertion; are available upon request; giving users even greater flexibility and control over their digital content. Also suitable Cable digital TV adjacent frequency front-end system; hotel IPTV network TV system and hotel satellite digital TV system.
Features:
FMUSER DTV-4335H/HV supports HEVC/H.265 and MPEG 4 AVC/H.264 video encoding format; which ensures high video quality even at lower bitrates; making it suitable for a wide range of applications.FMUSER DTV-4335H/HV also supports MPEG1 Layer II; LC-AAC; and HE-AAC audio encoding formats; as well as AC3 Pass Through and audio gain adjustment; allowing users to fine-tune the audio output to their specific requirements.FMUSER DTV-4335H/HV supports IP output over UDP and RTP/RTSP protocol; which enables easy integration with existing digital distribution systems.FMUSER DTV-4335H/HV supports QR code; LOGO; and caption insertion in multiple languages; making it suitable for use in a wide range of applications around the world.FMUSER DTV-4335H/HV supports OSD (On-Screen Display) functionality; allowing users to insert images; QR codes; text; and other visual elements into each encoded video stream. This feature provides users with greater flexibility and control over their digital content; enabling them to customize their programs and better engage with their audience.The device features a "Null PKT Filter" function; which ensures that only valid data is transmitted; reducing network traffic and improving overall system performance.Null PKT Filter is a data filtering function that can filter out invalid data packets in transmission. In digital distribution systems; the reliability and efficiency of data transmission is very important. If invalid packets are transmitted; they can consume network bandwidth and affect overall system performance. Use the Null PKT Filter function to filter out these invalid data packets; reduce network traffic; and improve system transmission efficiency and performance. Therefore; the Null PKT Filter function of the FMUSER DTV-4335H/HV multi-channel encoder can ensure data reliability and system efficiencyFMUSER DTV-4335H/HV can be controlled via web management; with easy updates via web; allowing users to configure the device to meet their specific requirements quickly and easily.
Chart of Per Module Principle:
Specification:
Input | 4/8/12×SDI/HD(1.4) input for option; HDCP 1.4 | ||||
Video Encoding | Encoding Format | HEVC/ H.265; MPEG 4 AVC/H.264 | |||
Resolution (DTV-4335HV) | Input | Output | |||
HEVC/H.265 | MPEG-4 AVC/H.264 | ||||
4*1080P-50 | 4*1080P-50 | 4*1080P-25 | |||
4*1080P-60/59.94 |
4*1080P-60; | 4*1080P-30 | |||
4*1080I-50 | 4*1080P-50; | 4*1080I-50 | |||
4*1080I-60/59.94 | 4*1080P-60; | 4*1080I-60 | |||
4*720P-50 | 4*720P-50 | 4*720P-50 | |||
4*720P-60/59.94 | 4*720P-60; | 4*720P-60 | |||
Resolution |
| Output | |||
Input | HEVC/H.265 | MPEG-4 AVC/H.264 | |||
4*1080P-50 | 4*1080P-50 | 4*1080P-50 | |||
4*1080P-60/59.94 | 4*1080P-60; | 4*1080P-60 | |||
4*1080I-50 | 4*1080P-50; | 4*1080P-25 | |||
4*1080I-60/59.94 | 4*1080P-60; | 4*1080P-30 | |||
4*720P-50 | 4*720P-50 | 4*720P-50 | |||
4*720P-60/59.94 | 4*720P-60; | 4*720P-60 | |||
Chroma | 4:2:0 | ||||
Bitrate | 0.5Mbps~20Mbps (HEVC/ H.265) | ||||
Rate Control | CBR/VBR | ||||
GOP Structure | IBBP; IPPP | ||||
Advanced | De-interlacing; Noise Reduction; Sharpening | ||||
Audio Encoding | Encoding Format | MPEG- 1 Layer 2; LC-AAC; HE-AAC; HE-AAC V2; AC3 Passthrough | |||
Sampling rate | 48KHz | ||||
| Bit-rate | 48Kbps~384Kbps (MPEG- 1 Layer 2 & LC-AAC) | |||
Audio Gain | 0~255 | ||||
Stream | 1 MPTS and 4 SPTS output over UDP/RTP/RTSP per module; Base-T Ethernet interface (1000M/100M self-adaption) (unicast/ multicast) | ||||
System | Web based management | ||||
Chinese-English control interface | |||||
Ethernet software upgrade | |||||
| Dimension (W× L× H) | 482mm×328mm×44mm | |||
Approx weight | 5kg | ||||
Temperature | 0~45C(work); -20~80C (Storage) | ||||
Power | AC 100V-220V±10%; 50/60Hz | ||||
Parameter Comparison:
| DTV-4335V-HD | DTV-4335V-SDI | DTV-4335H | DTV-4335HV | |
Input Interface | 4/8/12*HD | 4/8/12*SDI | 4/8/12*HD/SDI | 4/8/12*HD/SDI | |
Video Encoding | H.265; H.264 | H.265; H.264 | H.265; H.264 | H.265; H.264 | |
Audio Encoding | MPEG- 1 Layer 2; LC-AAC; HE-AAC; HE-AAC V2; AC3 Passthrough | ||||
Input Resolution |
H.265 |
3840x2160P@30*2CHs |
1920x1080P@50/60*4CHs |
1920x1080P@50 /60*4CHs /60*4CHs /60*4CHs | 4*1920x1080_60P/ |
H.264 |
3840x2160P@30*1CH |
1920x1080P@50/60*2CHs | 4or2*1920x1080_60P /59.94P | ||
Output Resolution |
H.265 |
3840x2160P@30*2CHs |
1920x1080P@50/60*4CH |
1920x1080P@50 /60*4CHs 1280x720P@50 /60*4CHs | 4*1920×1080_60P /59.94P |
H.264 |
3840x2160P@30*1CH |
1920x1080P@50/60*2CH | 2*1920×1080_60P /59.94P (HD 3 and HD 4) (HD 3 and HD 4) /29.97P | ||
OSD | N/A | N/A | Optional as per order | Optional as per order | |
Caption Language | N/A | N/A | Not support caption | Not support caption | |
Note: 'CH' means encoding channel; different encoding format can encode different channel with different resolution. | |||||
